  • iMira LED Poster
  • iMira LED Poster
iMira LED PosteriMira LED Poster

iMira LED Poster

iMira LED Display Screen

iMira specification download


Stylish Art Design Fashionable Ads catch the eyeballs

LED poster display screen

Stylish vanguard LED products

Fashionable Ads catch the eyeballs

Standard module size



Considering viewing distance of various projects, choose the best suitable pixel pitch and assemble standard module into big transparent led screen.


Easy and Quick Installation

The screen can be hung or mounted on the window Power supplies built into the frame, helping it easier and faster for installation

LED poster display screen


Fashionable Ads catch the eyeballs


> Ultra-slim and light weight (thickness 35mm)
>Plug and play system
> Intelligent central management
> Multiple installation methods
Floor standing, wall-mounting and hanging
> App control


LED poster display screen

※Ultra-slim and light weight

35mm thickness of the panel, 38kg/panel.

※Intelligent central management

Support multi-screen set networking, remote configuration and management, breakpoint upload, multiple connection play modes, mobile phone real-time. Photographing and editing, 360-degree arbitrary rotation, digital Dolby 5.1-channel audio output.

※Multiple installation methods

User-level front maintenance, support floor-standing, wall-mounting and hanging installation options, provides a horizontal or vertical installing and display mode.

※8:27 ratio enable 2K and 4K

With high refresh rate and gray level, the WLC is a fine pitch LED display with 1.895 and P2.5 pixel pitch using patented LEDs. Aiming at the middle and high-end market, we provide you with ultra-thin seamless LED display with flexible maintenance mode and reliable non-cable connection. Cabinet ratio 8:27 enables 2K and 4k, giving you a wonderful visual experience.


Technical specifications

Parameters

iMira   -Poster2nd Generation

Pixel Pitchmm

1.8 mm

2.571 mm

Pixel Configuration

SMD 1515

SMD 2020

Pixel Matrix per Paneldots

160 x 120 dots

112 x 84 dots

Pixel Densitydots/pcs

345,600 dots/pcs

169,344 dots/pcs

Panel Dimension (W×H×D) /mm

576 x 1944 x 35mm (80”)

576 x 1944 x 35mm (80”)

Panel Material

Aluminum / 10 colors optional

Aluminum / 10 colors optional

Screen the Weightkg/pcs

35 kg/pcs

35 kg/pcs

Color DepthBit

14 bit

14 bit

Refresh RateHz

3840 Hz

3840 Hz

Driver Method /scan

Scan 1/30

Scan 1/28

Brightnessnits

600~1200 nitsadjustable8   levels

600~1200 nitsadjustable8   levels

Horizontal Viewing Angle

160 °

160 °

Vertical Viewing Angle

160 °

160 °

Display Resolution (W×H) /pixel

320 x 1080

224 x 756

Control Mode

USB / HDMI / WIFI / RJ45

USB / HDMI / WIFI / RJ45

Support Video Mode

MP4AVI   WMV

MP4AVI   WMV

AC Power InputV

AC110V~ 220V ±10%

AC110V~ 220V ±10%

AC Power FrequencyHz

50 ~ 60 Hz

50 ~ 60 Hz

Max. PowerW/pcs

654 W/pcs

683 W/pcs

Avg. PowerW/pcs

218 W/pcs

228 W/pcs

Operating Temperature

- 0 ~ 50

- 0 ~ 50

Installation Type

Wall HangingStackingHanging

Wall HangingStackingHanging

Maintenance Method

Front service

Front service

Certifications

CCC

CCC
